Sorein SCAP-C Off - Grid 11kw Efficient Energy Storage System with Expandable 30kWh Battery

Inverter Parameters
Power: 11KW
Battery Input Voltage: 51.2V
Inverter Output Voltage: 230V
Maximum PV Input Power: 2*5500W
PV Input Voltage Range: 120V - 500V
MPPT Max Charging Current: 160A
Chassis Size: 70×26×51 cm

Battery Parameters
Voltage: 51.2V
Capacity: 15360Wh (300Ah)
Discharge Current: 200A
Battery Category: LiFePO4
Chassis Size: 70×26×51 cm

Inverter Parameters
Power: 11KW
Battery Input Voltage: 51.2V
Inverter Output Voltage: 230V
Maximum PV Input Power: 2*5500W
PV Input Voltage Range: 120V - 500V
MPPT Max Charging Current: 160A
Chassis Size: 70×26×51 cm

Battery Parameters
Voltage: 51.2V
Capacity: 30720Wh (600Ah)
Discharge Current: 400A
Battery Category: LiFePO4
Chassis Size: (70×26×51 cm)*2

The C Series energy storage systems are designed to meet different energy demands. The 15kWh model is suitable for medium - sized applications, while the 30kWh model can handle larger - scale power requirements. The inverters in both models are capable of handling high - power PV inputs, and the LiFePO4 batteries offer reliable energy storage with appropriate discharge capabilities. The consistent chassis size for the 15kWh components and the modular design for the 30kWh battery (with two units of the same - sized chassis) contribute to an organized and potentially space - efficient installation.
